Mineral

Exrtaction

Plant

Overview

Mineral extraction is a process for extracting minerals after ore mining.
The desired metal is extracted through the processes of mineral process, smelting and refining.

  • Mineral Process

        The Run of Mine (ROM) from the mine contains many of the unwanted gangue minerals as well as the beneficial minerals we want.​

         The process of crushing this ore and extracting the mineral we want by gravity, magnetic force, and surface characteristics is called

         Mineral Process. This process is to separate by physical action not chemical action. The ores that have undergone this process are called

         'ore concentration'. It is usually transported outside after Mineral Process in the mine. This process is also called 'Milling' or 'Beneficiation'.

  • Smelting

        Smelting is the process of obtaining a pure metal by using a chemical reduction reaction of a 'ore concentrate' sent from a mine.

         The process of iron extraction from iron ore (iron oxide), and the process of producing pure copper metal from copper concentrate is the

         smelting process. The smelting process is not carried out in the mines, but is carried out to the factories equipped with facilities.



  • Refining

         Refining is the process of increasing the purity of primary product from the smelting process.

Flow Diagram[ Lithium Extraction Process ]

RAW
MATERIAL
ROTARY
KILN
ROTARY
COOLER
BALL MILL
MIXER
ROASTING
KILN
ROASTION
COOLER
LEACHING
LITHIUM

1. The mined ore is calcined in a brittle state by heating at 1070 ° C through a rotary kiln for calcination, and then cooled to 200 ° C

    in a calcining rotary cooler

2. The cooled ores are crushed through a ball mill and mixed with sulfuric acid (H2SO4) in a mixer.

3. All the dust that is generated at this time is collected and supplied to the roasting process.

4. The crushed lithium ore is heated to 250 ° C in a roasting kiln and cooled again to 80 ° C through a roasting cooler.



5. At this time, the dust and smoke are completely sealed by the exhaust system so that they do not come out.

6. The cooled mixture extracts lithium from the leaching hopper.

Our Solutions

Crusher
3. Mixer.JPG
Mixer
Rotary Kiln
Rotary Kiln
ROTARY COOLER1.jpg
Rotary Cooler
